1.20 E1 Line Service Features
Feature Guide 189
1.20 E1 Line Service Features
1.20.1 E1 Line Service
Description
The E1 line carries thirty 64 kbps-voice channels at 2.048 Mbps transmission speed as a trunk
or private line. Voice is digitised by Pulse Code Modulation (PCM).
1. Channel Type
[DR2 (Digital System R2)/E & M-C (Continuous E & M)/E & M-P (Pulsed E & M)]
The E1 card supports three different channel types to provide connection at minimum
expense. One of the three channel types can be assigned to one of the 30 channels of the
E1 card individually according to tariffs and customer needs.
2. E1 Features
The following table shows the features available for each channel type:
[Feature Table]
Channel Type (1) TIE (2) DID (3) DIL (4) ANI
(5) Call Charge
Information
DR2 *1
E & M-C *2
E & M-P *2
: Available
*1 : Receiving Dial Mode should be MFC-R2.
*2 : Available only when this PBX is connected to the KX-TDA100, KX-TDA200, or KX-
TD500.
