1.16 Caller ID Features
154 Feature Guide
3.2 Caller ID Table Assignment
The System Speed Dialling Table is also used as the Caller ID Table.
In each location of the table, the following items can be assigned:
a) System Speed Dialling number (Trunk Access number + caller’s telephone
number)
b) System Speed Dialling name (caller’s name)
(shown on the display or SMDR)
c) CLI destination
(used for CLI feature)
When a caller’s modified telephone number matches a System Speed Dialling
number (the Trunk Access number is disregarded.) in the table, the call is sent to the
assigned CLI destination.
A trunk call with a caller's
information is received.
No:
e.g., 3344556677 Yes:
e.g., 00987654321
Is the area code found in
a local/international data
in the modification table?
Modifies the number as programmed.
Checks the local/
international call data.
Modification is completed:
001987654321.
Modification is completed:
03344556677.
Modifies the number as programmed.
(Removed number of digits: 0,
Added number: 0)
Checks the long distance call data.
Matches (Data 2)
Table 1
Removed number of digits: 2
Added number: 001
Received number: 00987654321
Modified number: 00987654321 = 001987654321
1) Remove the
first 2 digits.
2) Add "001".
Checks the Table Selection.
