Beispiel der Systemkonfiguration
Konvertierbare
Kamera
MONITOR1
Monitor
Monitor
Mit AW-CB400 geliefertes Kabel
Monitorumschaltung
Kabelkompensator
AW-RC400
Netzgerät
AW-PS505
Schwenk-/Neigekopf-
Steuergerät AW-RP400
Fernsteuerkonsole
AW-CB400
Kopfgarnitur
Kopfgarnitur
MONITOR2
Schwenk-/Neigekopf- und
Kamerasteuerung
Innenraum-Schwenk-
/Neigekopf AW-PH400
FBAS- oder
Komponenten-
Videosignale
Zum Bildmischpult,
Monitor
Genlocksignale
G/L
Netzgerät
AW-PS301
