The lasr2fls Utility Program
99
The lasr2fls Utility Program
The lasr2fls program is a DOS utility that is supplied with the
flash software on diskette. This utility converts logo, form, TIFF,
setup, and font files into downloadable format.
To convert files into downloadable format, do the following:
1. Create a directory on the hard drive and copy the lasr2fls
utility to that directory.
2. Copy all of the files to be converted to the directory where the
lasr2fls utility resides.
3. Change to the drive and directory where the lasr2fls utility
resides.
4. To display a brief help message, at the DOS prompt, enter the
command name
lasr2fls with no parameters:
lasr2fls
You will then see a help message similar to the following:
L50XX Laser Printer Flash File Conversion Utility, Vx.xx, mm/dd/yy
USAGE:
lasr2fls file_name1 file_name2 file_name3 A
or
lasr2fls file_name1 file_name2 file_name3 A FONT
file_name1: Input file name to be converted from.
file_name2: Output file name for file download.
file_name3: Flash file name to be stored in file system after download.
hw_type: Specify A all the time.
FONT: Optional, specify FONT if this is a font file.
