Appendix A Maintenance Log Sheets
202
Level F Maintenance - 900,000 Pages (Service)
Level G Maintenance - 1,200,000 Pages (Service)
Action Item Part # Performed By Date
Clean Flash power supply
filter n/a
Replace Main charger 705741-001
Replace Smoke filter 703540-001
Replace Xenon lamp 703541-001
Action Item Part # Performed By Date
Clean Lamp housing filter 202985-001
Clean Flash power supply filter n/a
Replace Main charger 705741-001
Replace Precharger 705742-001
Replace Transfer charger 705743-001
Replace
(See Note 1) Cleaning unit 705740-001
Replace Smoke filter 703540-001
Replace Transporting belt-3 703531-035
Replace Developer motor unit 202995-001
Note 1: When the cleaning unit has been vacuumed every 150,000 pages and has
been used under normal operating conditions, it must be replaced at 600,000 pages.
However, it may need to be replaced more frequently if used for high-density printing
or printing on uneven media, or if used under severe operating conditions.
