Dataproducts Parallel Interface
227
Centronics Parallel Interface Configuration
The printer is configured for the Centronics interface via the
Centronics Interface menu, as described on page 61. The following
interface configuration parameters may be modified to meet
specific application requirements:
NOTE: Only the factory default settings are shown above. See
page 61 for additional options.
Dataproducts Parallel Interface
This interface allows the printer to operate with controllers designed
for Dataproducts printers. The interface is capable of transferring
up to 500,000 characters per second. The maximum cable length
from the controller (host computer) to the printer is 40 feet.
Data Bit 8 Enable
P I Ignored Disable
Data Polarity Standard
Resp. Polarity Standard
Busy On Strobe Enable
Latch Data On Leading
Prime Signal Enable
TOF Action Reset
Buffer Size In K 64
