Liquid Crystal Display (LCD)
31
Using The Control Panel
The control panel is located on the top right side of the front cover.
Liquid Crystal Display (LCD)
The liquid crystal display (LCD) displays messages, printer
operating status, configuration options, and error codes.
Status Indicators
The status indicators display the current operational status of the
printer.
LINE SYNC
Twinax interface only. Indicates there is activity on the line from the
host computer.
JOB IN
PROCESS
STAND BY
LINE
SYNC
SYS
AVAIL
ONLINE
FAULT
ONLINE
CLEAR
TEST
SHIFT
CANCEL
PAGE
EJECT
ENTER
PREV
UP
NEXT
DOWN
Status
Indicators
Liquid Crystal
Display (LCD)
Paper Path
Diagram
Function
Keys
