Connecting the Printer
Network Connection
Follow the procedure below to connect the printer to the computer through the
network. Prepare the hub and other network devices before connecting the 10
BASE-T or 100 BASE-TX cable to the machine's Ethernet port.
❒ Use shielded Ethernet cable. Unshielded cables create electromagnetic inter-
ference that could cause malfunctions.
❒ Ethernet cable is not supplied with this machine. Select your cable according
to the network environment.
A
Attach one ferrite core at the printer end of the Ethernet cable, and then
attach the other ferrite core about 10 cm (4 inches) ( ) from this core.
B
Connect the Ethernet cable to the Ethernet port.
C
Connect the other end of the cable to the printer's network, such as a
hub.
For details about network environment settings, see Software Guide.
