Guide to the Printer
Exterior: Front View
1. Standard Tray
Output is stacked here print side down.
2. Upper Left Cover
Open this to replace toner cartridges.
3. Ventilator
The ventilator helps keep internal components from overheating. Overheating results in
malfunction. Make sure the ventilator is not blocked by objects or in any way obstructed.
4. Control Panel
Contains keys for printer control and a panel display that displays the printer's status.
5. Front Cover
Open this to replace the fusing unit or transfer roller, install the duplex unit, or remove
misfed paper.
6. Bypass Tray
Use this to print onto thick paper, OHP transparencies, custom size paper, and enve-
lopes, as well as plain paper. Special printer driver settings must be made in order to
print onto custom size paper.
7. Tray 1
Up to 530 sheets of plain paper can be loaded here.
