Konica Minolta Chroma Meter CS-200 - Manual (Page 68)

66
M
ea
su
re
m
en
t
Pr
ep
ara
tio
n
(1) Through measurement
7.
Press either
or key to select
[USER CAL] and then ENTER key.
< USER CAL DATA> screen appears.
8.
Use close-up lens, select measuring
angle, adjust finder diopter and focus.
For more details on each operation, see p.88.
Use light source of which luminance and
chromaticity are known on object.
9.
Press COLOR key in SHIFT mode,
and select color space.
Select same color space as calibration value
to be entered in procedures from
12
to
13
.
10.
Press measurement button
to start measurement.
Now starts measurement.
This measurement is performed with correction
coefficient (CH00) based upon KONICA
MINOLTA SENSING's calibration standard.
Measurement value appears on
part of LCD screen
after measurement is completed.
After measurement, do not switch OFF
until measurement value appears.
Doing so may break stored data.
continuation from a p.64, 65.
9 16 11, 15
13
7, 12 9
U
S
E
R C
A
L
<
CH SETTING
>
CH01:
<
DEFAULT
>
USER CAL
CH ID NAME
CH COPY
CH RESET
BREAK:[ESC]
[ ]  [ 2° ]
CH01:
Lv ------
cd/m 2
x ------
y ------
SELECT MEH DATA
OR MEASURE.
NEXT : [ENTER]
[ SFT]  [ 2° ]
<
ANGL
>
1° VIEW
<
SPD
>
AUTO
<
SYNC
>
NO SYNC
<
LENS
>
STANDARD
<
MEM
>
AUTO NUM
Lv ------
x ------
y ------
CH01:
Lv ------
cd/m 2
x ------
y ------
SELECT MEH DATA
OR MEASURE.
NEXT : [ENTER]
[ SFT]  [ 2° ]
<
ANGL
>
1° VIEW
<
SPD
>
AUTO
<
SYNC
>
NO SYNC
<
LENS
>
STANDARD
<
MEM
>
AUTO NUM
Lv 90.30
x 0.4210
y 0.4128
CH01:
Lv ------
cd/m 2
x ------
y ------
SELECT MEH DATA
OR MEASURE.
NEXT : [ENTER]
[ ]  [ 2° ]
<
ANGL
>
1° VIEW
<
SPD
>
AUTO
<
SYNC
>
NO SYNC
<
LENS
>
STANDARD
<
MEM
>
AUTO NUM
Lv ------
x ------
y ------
