Specification
Item CHROMA METER CS-200
Measurement range 0.01 - 200,000 cd/m 2 (Measuring angle 1˚)
0.01 - 5,000,000 cd/m 2 (Measuring angle 0.2˚)
0.01 - 20,000,000 cd/m 2 (Measuring angle 0.1˚)
Accuracy
(Measuring angle 1˚)∗1
(Temperature: 23˚±2˚,
RH 65% max.) 150 cd/m 2 (for illuminant A) L
v
±2 %±1digit xy ±0.002
0.01 - 0.5 cd/m 2 (for illuminant A) L
v
±0.02 cd/m 2 ±1digit ---
0.5 - 1 cd/m 2 (for illuminant A) L
v
±0.02 cd/m 2 ±1digit xy ±0.007
1 - 10 cd/m 2 (for illuminant A) L
v
±2 %±1digit xy ±0.004
10 - 200,000 cd/m 2 (for illuminant A) L
v
±2 %±1digit xy ±0.003
(5,000 cd/m 2 for illuminant A) color filter (R,G,B) xy ±0.006
Repeatability
(Measuring angle 1˚)∗2 0.01 - 1 cd/m 2 (for illuminant A) L
v
0.01 cd/m 2 +1digit --- (2 σ) (AUTO)
1 - 2 cd/m 2 (for illuminant A) L
v
0.5 %+1digit xy 0.002 (2 σ) (AUTO)
2 - 4 cd/m 2 (for illuminant A) L
v
0.5 %+1digit xy 0.001 (2 σ) (AUTO)
4 - 8 cd/m 2 (for illuminant A) L
v
0.5 %+1digit xy 0.0005 (2 σ) (AUTO)
8 - 200,000 cd/m 2 (for illuminant A) L
v
0.1 %+1digit xy 0.0004 (2 σ) (AUTO)
Measurement time Automatically set between approx. 1 sec/meas. and 60 sec/meas. (AUTO)
Automatically set to approx. 1 sec/meas. or 3 sec/meas. (LTD.AUTO)
approx. 0.5 sec/meas.(Super-FAST) approx. 1 sec/meas.(FAST)
approx. 3 sec/meas. (SLOW)
approx. 12 sec/meas. (Super-SLOW)
Measurement method Spectral method, Grating + linear photo diode array
Measuring angle 1˚, 0.2˚, 0.1˚ (Switchable)
Minimum measuring area ø0.5 mm, ø0.1 mm (With close-up lens No.107)
Minimum measuring
distance 296 mm (Distance from front edge of metal lens barrel)
Color space L
v
x y, L
v
u’ v’, L
v
T∆uv, XYZ, dominant wavelength
Measurement synchroniza-
tion frequency
Vertical synchronization frequency:40.00 to 200.00 Hz
Interface USB1.1
Power source AC adapter and 4 AA-Size Batteries
Battery life 3 hours approx. (in Continuous measurement/FAST mode, with AA-Size bat-
tery under company testing KONICA MINOLTA SENSING's conditions.)
Size 95 (W) x 127(H) x 334(L) mm
Weight 1.8 kg (without battery)
Operating temperature
/humidity range 0 to 40˚C, RH 85 % or less (at 35˚C) with no condensation
Storage temperature
/humidity range 0 to 40˚C, RH 85 % or less (at 35˚C) with no condensation
Standard accessory Lens cap, Holding cap CS-A24, ND eyepiece filter CS-A27, AC adapter AC-
A23, Data management software CS-S10w Standard, USB cable (2 m) IF-A17
Optional accessory Close-up lens No.107, Close-up lens No.122, ND filter (1/10) CS-A6,
ND filter (1/100) CS-A7, Calibration instruction (For ND filter),
Step up ring (40.5 to 55 mm) CS-A26, Angle finder V
N
, White calibration plate
(For 45-0) CS-A20, White calibration plate (For d-0) CS-A21, White calibra-
tion plate CS-A22, Soft case CS-A23, Data management software CS-S10w
Professional
∗1. 23˚C±2˚C, L
v
=0.01 to 10 cd/m 2 SLOW average of 30 measurements
L
v
= 10 cd/m 2 and higher SLOW average of 10 measurements
∗2. At 0.2˚ Measuring angle, the amount of received light is approx. 1/25 of that for 1˚.
Therefore, the repeatability becomes the same as that for 1˚ with 25 times lower luminance.
0.1˚ Measuring angle, the amount of received light is approx. 1/100 of that for 1˚.
Therefore, the repeatability becomes the same as that for 1˚ with 100 times lower luminance.
