64
M
ea
su
re
m
en
t
Pr
ep
ara
tio
n
Implementing User Calibration
User calibration cannot be conducted in calibration channel CH00.
(CH00 serves as calibration channel for measurement based on KONICA MINOLTA
SENSING’s calibration standard.)
When user calibration is performed in the calibration channel for which target color has
already been set, previous target color is cancelled.
These are commonly used among each color space of L
v
xy, L
v
u’v’, L
v
T∆uv, XYZ, and
dominant wavelength in one channel.
Operation Procedure
1.
Press ESC key when menu or target
value setting menu appears.
Measurement screen appears on LCD screen.
2.
Press SHIFT key to switch
to SHIFT mode.
[SFT] appears on left bottom indicating
this instrument is to operate in SHIFT
mode. Or make sure that [SFT] appears on
left bottom indicating that this instrument
has been operated in SHIFT mode.
3.
Press either
or key to
switch calibration channel and
select one for user calibration.
2 3 1, 10 4, 9 5
5, 7
4, 6
C
H
S
E
T
T
IN
G
CH 01 :
<
DEFAULT
>
Lv ------
cd/m 2
x ------
y ------
<
MODE
>
SINGLE
[ SFT]  [ 2° ]
<
ANGL
>
1° VIEW
<
SPD
>
AUTO
<
SYNC
>
NO SYNC
<
LENS
>
STANDARD
<
MEM
>
AUTO NUM
<
MEMORY DATA
>
M000 :(NO DATA)
Lv ------
x ------
y ------
CH 01 :
<
DEFAULT
>
Lv ------
cd/m 2
x ------
y ------
<
MODE
>
SINGLE
[ SFT ]  [ 2° ]
<
ANGL
>
1° VIEW
<
SPD
>
AUTO
<
SYNC
>
NO SYNC
<
LENS
>
STANDARD
<
MEM
>
AUTO NUM
<
MEMORY DATA
>
M000 :(NO DATA)
Lv ------
x ------
y ------
