PLC-WXE46/WXL46
Expand Serial Command Functional Specifications
57/65
9.11.5 CR_CEIL Command
Command “CR_CEIL” [CR]
Details
Get setting status of Ceiling
Response
Acceptable
“000_%1”[CR]
%1
“ON” ------------------------------ Ceiling is ON
“OFF” ----------------------------- Ceiling is OFF
Unacceptable “Error Code” [CR]
9.11.6 CR_REAR Command
Command “CR_REAR” [CR]
Details
Get setting status of Rear
Response
Acceptable
“000_%1”[CR]
%1
“ON” ------------------------------ Rear is ON
“OFF” ----------------------------- Rear is OFF
Unacceptable “Error Code” [CR]
9.11.7 CR_SCREENASPECT Command
Command “CR_SCREENASPECT”[CR]
Details
Get setting status of Screen aspect
Response
Acceptable
“000_%1”[CR]
%1
“43MODE” ------------ 4:3 mode is selected.
“169MODE” ---------- 16:9 is selected.
“1610MODE” -------- 16:10 is selected.
Unacceptable “Error Code”[CR]
9.11.8 CR_TERMINAL Command
Command “CR_TERMINAL”[CR]
Details
Get setting status of Terminal
Response
Acceptable
“000_%1”[CR]
%1
“COMPUTER” ------------------ Computer input is seleted
“MONITOR” --------------------- Monitor out is setected.
Unacceptable “Error Code”[CR]
9.11.9 CR_INPUTSEARCH Command
Command “CR_INPUTSEARCH”[CR]
Details
Get setting status of Input search
Response
Acceptable
“000_%a”[CR]
%a
“OFF” --------------------- Input search is OFF
“ON1” --------------------- Input search is On1
“ON2” --------------------- Input search is On2
Unacceptable “Error Code”[CR]
