PLC-WXE46/WXL46
Expand Serial Command Functional Specifications
38/65
8.10.21 CF_CCAPTIONDISP Command
Command “CF_CCAPTIONDISP_%1”[CR]
%1
“OFF” ------------- Select Off
“CC1” ------------- Select CC1
“CC2” ------------- Select CC2
“CC3” ------------- Select CC3
“CC4” ------------- Select CC4
Details
Select channel of Closed caption.
The status set with this command is stored in EEPROM and its setting is effective
even after ALL is OFF.
Note1) This command is available in normal Power ON status.
Note2) Closed caption is available under conditions below;
Entered signal is appropriate (Video, NTSC signal of S-video, Component=480i)
and System is fixed to NTSC or 480i.
Response
Acceptable
“000”[CR]
Unacceptable “Error Code”[CR]
8.10.22 CF_CCAPTIONCOLOR Command
Command “CF_CCAPTIONCOLOR_%1”[CR]
%1
“COLOR” ------- Select Color
“WHITE” -------- Select White
Details
Select color of Closed caption.
The status set with this command is stored in EEPROM and its setting is effective
even after ALL is OFF.
Note1) This command is available in normal Power ON status.
Note2) Closed caption is available under conditions below;
Entered signal is appropriate (Video, NTSC signal of S-video, Component=480i)
and System is fixed to NTSC or 480i.
Response
Acceptable
“000”[CR]
Unacceptable “Error Code”[CR]
8.10.23 CF_FDEFAULT Command
Command “CF_FDEFAULT_%1”[CR]
%1
“RST”
Details
Set the value to Factory Default
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable “Error Code”[CR]
8.10.24 CF_ LOGOCAPTURE Command
Command “CF_LOGOCAPTURE_%1”[CR]
%1
“START” ------- Capture starts.
Details
Capture current projecting image.
Other commands are invalid while capturing image and projector returns “301” by
receiving commands at this moment.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
“101”-----when Logo is locked and projecter cannot operate
Capture.
