PLC-WXE46/WXL46 Expand Serial Command Functional Specifications
22/65
8.5.7 CF_DLINE Command
Command “CF_DLINE_%1”[CR]
%1
“0100”~”nnnn” --- Directly select Display Line setting value
“nnnn” shows maximum value, it is current Total Line value – Vertical
Position value
“UP” -------------- Current Display Line setting value + 1
“DN” -------------- Current Display Line setting value – 1
Details
Set Display Line value of PC signal
The value set by this command will not be saved to projector. Therefore, when
turning into Stanby mode or ALL is OFF, the value returns to original setting.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “101”[CR] ---- When Input for Video is selected
8.5.8 CF_PCSTORE Command
Command “CF_PCSTORE_%1”[CR]
%1
“MODE1” ---- Store current PC Adjust status to Mode1
“MODE2” ---- Store current PC Adjust status to Mode2
“MODE3” ---- Store current PC Adjust status to Mode3
“MODE4” ---- Store current PC Adjust status to Mode4
“MODE5” ---- Store current PC Adjust status to Mode5
Details
Store current PC Adjust status (each parameter status such as Total dots) to
Mode1~Mode5. This command operates the same way as storing to
Mode1-Mode5 in PC Adjust MENU.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “101”[CR] ---- When Input for Video is selected
8.5.9 CF_PCMODEFREE Command
Command “CF_PCMODEFREE_%1”[CR]
%1
“MODE1” ---- Set Mode1 to Free status
“MODE2” ---- Set Mode2 to Free status
“MODE3” ---- Set Mode3 to Free status
“MODE4” ---- Set Mode4 to Free status
“MODE5” ---- Set Mode5 to Free status
Details
Delete the registered data in Mode1-Mode5 and turns it to Free status.
This command operates the same as turning Mode1-Mode5 to Free in PC Adjust
Menu.
This command is available in normal Power ON status.
Response
Acceptable “000”[CR]
Unacceptable “101”[CR] ---- When Input for Video is selected
