2-22
X6DH3-G2/X6DHi-G2 User's Manual
2-6 Jumper Settings
Explanation of
Jumpers
To modify the operation of the
motherboard, jumpers can be
used to choose between optional
settings. Jumpers create shorts
between two pins to change the
function of the connector. Pin 1 is
identifi ed with a square solder pad
on the printed circuit board. See
the motherboard layout pages for
jumper locations.
Note: On two pin jumpers, "Closed"
means the jumper is on and "Open"
means the jumper is off the pins.
GLAN Enable/Disable
JPL1/JPL2 enables or disables the
GLAN port(s) on the motherboard.
See the table on the right for jumper
settings. The default setting is en-
abled.
GLAN 1 Enable
GLAN 2 Enable
Connector
Pins
Jumper
Setting
3 2 1
3 2 1
LAN1
®
JLAN
1
S
UPER X6DH3-G2
LAN2
DIMM 2A
DIMM 2B
DIMM 3A
DIMM 3B
DIMM 4A
DIMM 4B
DIMM 1B
DIMM 1A
12V 8-pin
PWR
JF
1
FP
Control
JOH
IPMI
ID
E2
Floppy
BIOS
Fan4 SMB
PCI-X100 MHz
PCI-X 100 MHz ZCR (Green Slot)
PCI-X 133 MHz
Battery
JPL1
PCI-E X8
VGA
COM1
USB
0/1
KB/MS
Fan6 Fan5
ATX PWR
12V 4-Pin
PWR
Parrallel Port
24-Pin
Fan7
JPW1
Fan8
CPU1
S I/O
PSF
Fan3
ID
E
1
PCI-33 MHz
USB2/3
ICH
JPG1 JWD
Slot1
Slot2
Slot3
Slot4
Slot5
Slot6
PCI-E X8
GLAN
CTRL
6300ESB
Buzzer
PXH
JBT1
I-SATA1
GLAN
CTRL
JPL2
JL1
JPS1
SAS
CTRL
Fan2
Fan1
JAR J3P
CPU2
E7520
Bank1
Bank2
Bank3
Bank4
WOL
SEPC
COM2
SMB PS
JWOR JS10
VGA
CTRL
JD1
JI 2 C2 I-SATA0
DS5 DS6 DS7 DS8
DS1 DS2 DS3 DS4
SAS4-7
SAS0-3
JSM1
JS9
JP9
J1D1
J32
J38
J33
J14
J7
JLAN1
JLAN2
JI 2 C1
J31
JSM2
JP1
GLAN Enable
Jumper Settings
Jumper Setting Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled
