Use the Point ◄► buttons to
adjust the value.
Press the MENU button to display the On-Screen
Menu. Use the Point
◄►
buttons to move the red
frame pointer to the Image Adjust Menu icon.
1
2
Use the Point ▲▼ buttons to move the red frame
pointer to the desired item, and then press the
SELECT button. The level of each item is displayed.
Use the Point ◄► buttons to adjust each level.
Move the red frame pointer
to the desired item and then
press the SELECT button.
Ima�e Adjust Menu
Press the Point ◄ button to decrease the contrast; press the
Point ► button to increase the contrast (from 0 to 63).
Press the Point ◄ button to decrease the brightness; press
the Point ► button to increase the brightness (from 0 to 63).
Contrast
Bri�htness
Image Adjust Menu icon
Press the Point ◄ button to lighten the red tone; press the
Point ► button to deepen the red tone (from 0 to 63).
White balance (Red)
Press the Point ◄ button to lighten the green tone; press the
Point ► button to deepen the green tone (from 0 to 63).
White balance (Green)
Press the Point ◄ button to lighten the blue tone; press the
Point ► button to deepen the blue tone (from 0 to 63).
White balance (Blue)
Selected Image level
Use the Point ◄► buttons to select the desired Color temp.
level (XLow, Low, Mid, or High).
Color temp.
Ima�e Level Adjustment
Note:
After adjusting the White balance Red,
Green, or Blue, the Color temp. level will
change to “Adj.”.
Use the Point ◄► buttons to adjust the gamma value to get
better balance of contrast (from 0 to 15).
Gamma
Press the Point ◄ button to decrease the sharpness of the
image; press the Point ► button to increase the sharpness
of the image (from 0 to 15).
Sharpness
To reset the adjusted data, select “Reset” and press the
SELECT button. A confirmation box appears and then select
“Yes.” All adjustments return to their previous figures.
Reset
1
Computer Input
