Press the MENU button to display the On-Screen
Menu. Use the Point ◄► buttons to move the red frame
pointer to the PC Adjust Menu icon.
1
2
Use the Point ▲▼ buttons to move the red frame
pointer to the desired item and then press the SELECT
button to display the adjustment dialog box. Press the
Point ◄► buttons to adjust the value.
Move the red frame pointer
to the desired item and
press the SELECT button.
PC Adjust Menu
PC Adjust Menu icon
Use the Point ◄► buttons to adjust the value to cut off
flicker from the image displayed (from 0 to 31).
Fine sync
Use the Point ◄► buttons to adjust the number of total dots
in one horizontal period to match your PC image.
Total dots
Use the Point ◄► buttons to adjust the horizontal picture
position.
Horizontal
Use the Point ◄► buttons to adjust the vertical picture
position.
Vertical
Press the SELECT button to show H-sync freq. and V-sync
freq. of the connected computer.
Current mode
Use the Point ◄► buttons to adjust the clamp level. When
the image has dark bars, try this adjustment.
Clamp
Press the SELECT button
here to move on to other
items.
Use the Point ◄► buttons
to adjust the value.
Status (Stored/Free) of the
selected Mode.
Selected Mode
Press the SELECT button
at “Current mode” to
show the information of
the connected computer.
Manual PC Adjustment
Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector.
Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The
projector has five independent memory areas (Mode 1–5) to store those parameters manually adjusted, which
allows you to recall the setting for a specific computer.
8
Computer Input
