AN93
Rev. 1.3 127
Table 86. EM In-Band Commands and Statuses
Command–
Indicator pair
Hex
Code
Transmit Direction Receive Direction
Supported
in
Transparent
Submode
Supported
in Framed
Submode
0x5C Transmit one 0x19 byte Received one 0x19 byte Yes
1
Yes
1
0x76 Transmit one 0x99 byte Received one 0x99 byte Yes
1
Yes
1
0xA0 Transmit one 0x11 byte Received one 0x11 byte Yes
1
Yes
1
0xA1 Transmit one 0x13 byte Received one 0x13 byte Yes
1
Yes
1
0x5D Transmit two 0x19 bytes Received two 0x19 bytes Yes Yes
0x77 Transmit two 0x99 bytes Received two 0x99 bytes Yes Yes
0xA2 Transmit two 0x11 bytes Received two 0x11 bytes Yes Yes
0xA3 Transmit two 0x13 bytes Received two 0x13 bytes Yes Yes
0xA4 Transmit 0x19, 0x99 Received 0x19, 0x99 Yes Yes
0xA5 Transmit 0x19, 0x11 Received 0x19, 0x11 Yes Yes
0xA6 Transmit 0x19, 0x13 Received 0x19, 0x13 Yes Yes
0xA7 Transmit 0x99, 0x19 Received 0x99, 0x19 Yes Yes
0xA8 Transmit 0x99, 0x11 Received 0x99, 0x11 Yes Yes
0xA9 Transmit 0x99, 0x13 Received 0x99, 0x13 Yes Yes
0xAA Transmit 0x11,0x19 Received 0x11,0x19 Yes Yes
0xAB Transmit 0x11,0x99 Received 0x11,0x99 Yes Yes
0xAC Transmit 0x11,0x13 Received 0x11,0x13 Yes Yes
0xAD Transmit 0x13,0x19 Received 0x13,0x19 Yes Yes
0xAE Transmit 0x13,0x99 Received 0x13,0x99 Yes Yes
0xAF Transmit 0x13,0x11 Received 0x13,0x11 Yes Yes
0xB0 Begin Transparent Mode
Abort Detected in Framed
Submode
Yes
Yes, Receive
Only
0xB1
Transmit a flag; enter
Framed Submode if cur-
rently in Transparent Sub-
mode. If +ESA[E] = 1,
append FCS to end of
frame before sending
closing HDLC flag.
Detected a non-flag to flag
transition. Preceding data was
a valid
frame. If +ESA[E]=1, sent FCS
matches that of the calculated
CRC.
Yes
