5-2 Sun Fire V120 and Netra 120 Server User’s Guide • December 2001
5.1 Installing Into a 19-Inch Four-Post Rack
5.1.1 The 19-Inch Rackmounting Kit
The mounting slides can each be used on either side of the rack. The parts required
are listed in
TABLE 5-1 . The part number of the rackmounting kit is X6919A (see
Section 1.3, “Optional Hardware and Software” on page 1-5).
A bracket is provided to aid cable management at the back of the server (see
FIGURE 5-1 ).
FIGURE 5-1 Cable Management Bracket
TABLE 5-1 19-inch Rackmounting Kit
Item Quantity Part No.
Front slide 2 340-6125
Rear slide 2 340-6234
Cable management bracket 1 340-6151
M4 nuts 4 240-1373
Rack screw kit 1 565-1645
