GM47/GM48 INTEGRATOR’S MANUAL
68
LZT 123 7263 R1C
3. Antenna Connector
The module’s antenna connector allows transmission of the radio
frequency (RF) signals from the module to an external customer-
supplied antenna. The connector is a micro-miniature coaxial MMCX
surface mounted component. A number of suitable MMCX type,
mating plugs are available from the following manufacturers;
• Amphenol;
• Suhner;
• IMS Connector Systems.
The electrical characteristics of the antenna interface are shown below.
Parameter Limit Description
Nominal impedance 50 Ω
Output Power
2 Watt peak (Class 4) Extended GSM900
1 Watt peak (Class 1) GSM1800
Static Sensitivity
Better than –102dBm Extended GSM900
Better than –102dBm GSM1800
