S ETUP G UIDE 5
English
Step 2.
Understanding Your Printer
These are the main components of your printer:
N OTE : The surface of the output tray may become hot if you print
a large number of pages at once. Please make sure that you don’t
touch the surface, and prevent children from approaching it.
Top Cover
(Open to install the
transfer belt.)
Output Support
Control Panel
(Refer to
Chapter 2 in the
User’s Guide on
the CD-ROM.)
Paper Output Tray
Front Cover
(Open to replace
the waste toner
container.)
Left Cover
(Open fully to install toner
cartridges and to press the top
cover release button.)
Tray 1
(250-sheet paper feeder)
Top Cover
Release Button
Optional Tray 2
(500-sheet paper feeder)
Handle
(Use it to lift the
printer.
Lifting handles are
located at the lower
edge of both sides
of the printer.)
