C.13
C
3 Press the scroll button ( or ) until “Yes” displays on
the bottom line. Press the Enter button ( ).
4 Press the Upper Level button ( ).
5 Press the scroll button ( or ) until “Config 802.11b”
displays on the bottom line. Press the Enter button ( ).
6 Press the scroll button ( or ) until “Yes” displays on
the bottom line. Press the Enter button ( ).
You can configure the following items:
• SSID: When you select “Search List”, the wireless network
card on your printer searches for wireless networks in the
area and shows the results on the list. Select a network from
the list. You cannot change “Operation Mode” and “Channel”.
If you select “Custom”, you can configure the wireless settings
according to your needs and enter a name of up to 32 letters
for your “Custom” setting. “SSID” is case sensitive, so you
need to change it carefully. Using the scroll buttons, find the
alphabet you want and press the Enter button ( ). When the
cursor moves to the next input field, enter the following letters
the same way you entered the first letter. After you have
entered the last letter of the name, press the Enter button
( ) once again to save the ID. The way to enter the key
number for the encryption key is the same as to enter letters.
• Operation Mode: “Ad-hoc” mode allows the wireless devices
to communicate directly with each other. This is the default
operating mode for the print server.
If your network uses an Access Point, you must reconfigure
the operation mode to “InfraStructure”. “InfraStructure” mode
allows both wireless and cabled computers to send files to the
printer through an Access Point.
If you select “Auto”, the print server selects the operation
mode automatically, according to the network cable’s
connection each time it boots up. If the network cable is
detected, the print server enters “Ad-hoc” mode; if not, it
enters “InfraStructure” mode.
• Channel: This option is available in the “Ad-hoc” mode only.
In most cases, you will not need to change this setting. The
print server will scan all available channels for the specified
network and will adapt its channel to the one detected. The
default setting is 10.
• Authentication: “Open System” or “Shared Key”. The
Samsung print server is not configured for network
authentication (Open System). If required by your network,
the proper authentication method must be configured on the
print server.
U SING Y OUR P RINTER ON A N ETWORK
