Cleaning the Mouse
Use the following information to clean the mouse:
1. Remove the retaining ring by turning it counterclockwise, in the direction of the
arrow as shown in the illustration.
1
2
3
1 Retaining ring
2 Ball
3 Cavity
2. Remove the ball.
3. Inspect the ball for contaminants. Wipe it clean with a dry, lint-free cloth.
4. If the ball is dirty, wash it in warm, soapy water. Rinse and wipe the ball with a
lint-free cloth until dry.
5. Inspect the ball cavity in the mouse for foreign materials. If there are any foreign
materials, remove them.
6. Replace the ball.
7. Replace the retaining ring on the mouse and align it with the open slots in the
ball cavity.
8. Turn the retaining ring clockwise until the open slots are covered and you hear
the ring snap into place.
2-14 7046 Model B50 User's Guide
