1-C1.1 Identifies CPU 1 on CPU card 1 on planar 1.
P2/Z1-A3.1 Identifies a SCSI device with a SCSI address of LUN 1 at SCSI ID 3
attached to SCSI bus 1 from planar 2.
P1-I2#E3.2 Identifies the second cable in a series of cables attached to Ethernet
controller 3 in slot 2 (I2) on planar 1.
Depending on the AIX and firmware levels, AIX Diagnostics may include extended
location information when identifing a planar or card. The extended location
information is always included when identifing a cable or connector. Location codes
with extended location information that display without a description identifing the
devices, always identify the cable attached to the port.
Name AIX
Location
Code Location
Code Physical
Connection Logical
Identification
System Planar 00-00 P1
Riser Card P1.1 J39
Memory DIMM 1 00-00 P1-M1 J11
Memory DIMM 2 00-00 P1-M2 J28
Memory DIMM 3 00-00 P1-M3 J19
Memory DIMM 4 00-00 P1-M4 J39
Diskette Drive 01-D1-00-00 P1-D1 J16 Base Address
0x03F0
Keyboard 01-K1-00-00 P1-K1 J59 Base Address
0x0060
Mouse 01-K1-01-00 P1-O1 J56 Base Address
0x0060
Audio Port 01-Q2 P1/Q2
Diskette Port 01-D1 P1/D1 J16 Base Address
0x03F0
Keyboard Port 01-K1-00 P1/K1 J59 Base Address
0x0060
Mouse Port 01-K1-01 P1/O1 J56 Base Address
0x0060
Serial Port 1 01-S1 P1/S1 J24 Base Address
0x03F8
Serial Port 2 01-S2 P1/S2 J23 Base Address
0x02F8
6-2 7046 Model B50 User's Guide
