Removing an Internal Drive

1. Remove the disk drive bay cover by loosening the thumbscrew.

2. Gently pull the right side of the drive cover towards you until you can remove the

cover completely from the server.

3. Press together the tabs located on the left side of the disk drive carrier handle

and pivot the handle towards you. This disconnects the drive carrier from the
rear connector.

4. Continue pulling the drive carrier out of the bay until it is completely removed.

5. If you are installing a new drive in the same bay, go to “Installing an Internal

Drive into an Empty Bay” on page 4-29. If not, replace the disk drive bay cover.
