Theory of Operation: Transceiver Board
2-15
2.4.3.8.1 Power and Control
Since U104 is powered from switched B+, it makes its own regulated 4.5 Vdc to power the internal
logic. The supply input is V5EXT at pin 17, and the output is V45 at pin 16. ANO at pin 32 is the
control signal to the RX/TX antenna switch control circuit.
2.4.3.8.2 Automatic Level Control (ALC)
In TX mode, the PCIC disables the receiver, turns on the transmitter, and controls the TX power
level. The automatic level control (ALC) circuit operates as follows:
The power level is set by programming an internal DAC to a calibrated reference voltage. D/A
settings for the power set points were determined during radio tuning and stored in EEPROM. An
internal op-amp compares the D/A reference voltage to the detector voltage at pin 1(RFIN) (TP101)
and produces an error signal output. This signal is buffered by another op-amp, configured as a low-
pass filter, or integrator, to produce the INT output at pin 4 (TP111).
This INT output supplies voltage to drive the gain control pins of amplifiers U102 and Q107.
Resistors R105 and R106 determine the voltage ratio between U102 pin 1 (VCNTRL) and the Q107
gate. Transient response during key-up and key-down is controlled by the power amplifier rise and
fall times. External capacitors at pins CI, CJ, and CL, along with internal programmable resistors,
determine the ALC time constants.
2.4.3.8.3 Temperature Cut Back
The PCIC contains a temperature cut-back circuit to protect the power amplifier (PA) from thermal
damage that might result from incorrect assembly of the radio. External sensor U103 is a linear
temperature-to-voltage transducer, placed near the hottest spot in the radio: power module Q107.
18
VAR2
Buffered D/A output
19
VLIM
Test point for internal D/A No.2 voltage
20
VAR1
Buffered D/A output
21
RS
Asynchronous reset input
22
NA
Spare pin
23
RX
RX/TX mode control-bit output
24
VAR3
Buffered D/A output
25
GND2
Ground
26
CLK
SPI clock input
27
BPOS
Power supply input
28
DATA
SPI data input/output
29
CEX
SPI chip select input
30
TEMP
Temperature sensor input
31
RSET
External resistor; used to set the temperature cutback rate
32
ANO
Switched BPOS output
Table 2-8. Power Control IC (U104) Pin Descriptions (Continued)
Pin
Name
Description
