Motorola SSETM 5000 - Manual (Page 179)

Schematics, Board Layouts, and Parts Lists: Transceiver (RF) Board 12-13
6881094C12-A November 11, 2004
C398 NOTPLACED 64AM DUMMY PART
NUMBER
C399 NOTPLACED 64AM DUMMY PART
NUMBER
C4 2113743L41 CAP CHIP 10000 PF 10%
X7R
C400 2113743N50 CAP CHIP 100 PF 5% COG
C401 2113743N65 CAP CHIP 8.0PF 16V .5PF
COG
C402 2113743N29 CAP 13PF 20X40
C403 2113743N64 CAP CHIP 7.0PF 16V .5PF
COG
C404 2113743N58 CAP CHIP 4.0PF 16V .25PF
COG
C405 2113743N28 CAP CHIP 12.0 PF 5% COG
C406 2113743N28 CAP CHIP 12.0 PF 5% COG
C407 2113743N29 CAP 13PF 20X40
C408 2113743N64 CAP CHIP 7.0PF 16V .5PF
COG
C409 2113743N65 CAP CHIP 8.0PF 16V .5PF
COG
C421 2113743N65 CAP CHIP 8.0PF 16V .5PF
COG
C422 2113743N28 CAP CHIP 12.0 PF 5% COG
C423 2113743N28 CAP CHIP 12.0 PF 5% COG
C424 2113743N64 CAP CHIP 7.0PF 16V .5PF
COG
C425 2113743N58 CAP CHIP 4.0PF 16V .25PF
COG
C426 2113743N28 CAP CHIP 12.0 PF 5% COG
C427 2113743N64 CAP CHIP 7.0PF 16V .5PF
COG
C428 2113743N28 CAP CHIP 12.0 PF 5% COG
C429 2113743N65 CAP CHIP 8.0PF 16V .5PF
COG
C430 2113743N50 CAP CHIP 100 PF 5% COG
C433 2113743E20 CAP CHIP .10 UF 10%
C434 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C435 2113743N30 CAP CHIP 15.0 PF 5% COG
C436 2113743N44 CAP CHIP 56.0 PF 5% COG
C444 2113743N50 CAP CHIP 100 PF 5% COG
Ref.
Des.
Motorola Part
Number
Description
C445 2113743N50 CAP CHIP 100 PF 5% COG
C471 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C472 2113743N50 CAP CHIP 100 PF 5% COG
C473 2113743N50 CAP CHIP 100 PF 5% COG
C474 2113743L29 CAP CHIP 3300 PF 10% X7R
C475 2113740F47 CAP CHIP REEL CL1 +/-30
68
C490 2113740F15 CAP CHIP REEL CL1 +/-30
3.3
C491 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C492 2113743N50 CAP CHIP 100 PF 5% COG
C494 2104801Z06 CAP CER NPO 1.0PF 16V
1005 SMD
C5 2113743T19 CAP 10UF 16V CER 3225
X5R
C501 2113743N54 CAP CHIP 150 PF 5% COG
C512 NOTPLACED 64AM DUMMY PART
NUMBER
C515 2113743L41 CAP CHIP 10000 PF 10%
X7R
C516 2113743L17 CAP CHIP 1000 PF 10% X7R
C517 2113743L41 CAP CHIP 10000 PF 10%
X7R
C518 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C519 2113743L41 CAP CHIP 10000 PF 10%
X7R
C520 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C521 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C522 2113743L41 CAP CHIP 10000 PF 10%
X7R
C523 2113743N50 CAP CHIP 100 PF 5% COG
C524 2113743N50 CAP CHIP 100 PF 5% COG
C525 2113743L41 CAP CHIP 10000 PF 10%
X7R
C526 2113743L25 CAP CHIP 2200 PF 10% X7R
C528 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
Ref.
Des.
Motorola Part
Number
Description
C529 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C530 2113743L41 CAP CHIP 10000 PF 10%
X7R
C532 2113743L41 CAP CHIP 10000 PF 10%
X7R
C533 2113743N50 CAP CHIP 100 PF 5% COG
C534 2113743N50 CAP CHIP 100 PF 5% COG
C535 2113743N46 QAP CHIP 68.0 PF 5% COG
C536 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C537 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C539 2113743L41 CAP CHIP 10000 PF 10%
X7R
C541 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C542 2113743N28 CAP CHIP 12.0 PF 5% COG
C543 2113743L41 CAP CHIP 10000 PF 10%
X7R
C550 2113743E20 CAP CHIP .10 UF 10%
C552 2113743L17 CAP CHIP 1000 PF 10% X7R
C553 2113743L50 CAP CHIP 33000 PF 10%
C554 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C555 2113743N30 CAP CHIP 15.0 PF 5% COG
C556 2113743N42 CAP CHIP 47.0 PF 5% COG
C557 2113743N42 CAP CHIP 47.0 PF 5% COG
C558 2113946D01 CAP CER CHP 0.47UF 6.3V
10%
C559 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C560 2113743N36 CAP CHIP 27.0 PF 5% COG
C570 2113743A24 CAP CHIP .330 UF 10% 16V
C571 2113743A24 CAP CHIP .330 UF 10% 16V
C6 2113743S01 CAP CER CHIP 1.0 UF 10%
16V
C601 NOTPLACED 64AM DUMMY PART
NUMBER
C7 2113743L41 CAP CHIP 10000 PF 10%
X7R
C70 2113743T19 CAP 10UF 16V CER 3225
X5R
Ref.
Des.
Motorola Part
Number
Description
C701 2113740F51 CAP CHIP REEL CL1 +/-30
100
C703 2113740F51 CAP CHIP REEL CL1 +/-30
100
C704 2113740F12 CAP CHIP REEL CL1 +/-30
2.4
C706 2113740F18 CAP CHIP REEL CL1 +/-30
4.3
C707 2113740F51 CAP CHIP REEL CL1 +/-30
100
C709 2113740F14 CAP CHIP REEL CL1 +/-30
3.0
C710 2113740F16 CAP CHIP REEL CL1 +/-30
3.6
C711 2113740F11 CAP CHIP REEL CL1 +/-30
2.2
C712 2113740F23 CAP CHIP REEL CL1 +/-30
6.8
C713 2113740F19 CAP CHIP REEL CL1 +/-30
4.7
C714 2113740F51 CAP CHIP REEL CL1 +/-30
100
C716 2113740F14 CAP CHIP REEL CL1 +/-30
3.0
C717 2113740F16 CAP CHIP REEL CL1 +/-30
3.6
C718 2113740F23 CAP CHIP REEL CL1 +/-30
6.8
C719 2113740F08 CAP CHIP REEL CL1 +/-30
1.6
C720 2113740F10 CAP CHIP REEL CL1 +/-30
2.0
C721 2113740F51 CAP CHIP REEL CL1 +/-30
100
C722 2113740F51 CAP CHIP REEL CL1 +/-30
100
C723 2113740F51 CAP CHIP REEL CL1 +/-30
100
C724 2113740F51 CAP CHIP REEL CL1 +/-30
100
C725 2113740F51 CAP CHIP REEL CL1 +/-30
100
C726 2113740F13 CAP CHIP REEL CL1 +/-30
2.7
Ref.
Des.
Motorola Part
Number
Description
