Page 137
6881094C12-A
November 11, 2004
Troubleshooting Tables: List of Board and IC Signals
10-3
12
GND
NA
13
UC_INT_PTT
R216
14
UC_RTA0
R235
15
UC_SCAN
R256
16
UC_RTA1
R236
17
UC_SEC_CLEAR
R234
18
UC_RTA2
R239
19
GND
NA
20
UC_RTA3
R241
Table 10-4. J701 VOCON Board to Encryption Module
J701
Pin No.
Description
To/From
1
KEYFAIL_LH_BDMDATA
U305, pin 1
2
NO CONNECT
3
NO CONNECT
4
NO CONNECT
5
NO CONNECT
6
NO CONNECT
7
SW_B+
C101
8
NO CONNECT
9
NO CONNECT
10
NO CONNECT
11
NO CONNECT
12
NO CONNECT
13
NO CONNECT
14
NO CONNECT
15
BOOT_ENC
U401
16
NO CONNECT
17
NO CONNECT
18
NO CONNECT
Table 10-3. J707 VOCON Board to Controls Flex Assembly (Continued)
J707
Pin No.
Description
To/From
