12-32 Schematics, Board Layouts, and Parts Lists: VOCON Board
November 11, 2004 6881094C12-A
R728 0662057M98 RES. CHIP 10K 5% 20X40
SH401 2685752E01 SHIELD SUB PATRIOT
SH500 2685533E01 SHEILD
SH600 NOTPLACED 64AM DUMMY PART NUMBER
U201 5109731C15 IC OP AMP SNGL OPA237
SOT23
U202 5109731C15 IC OP AMP SNGL OPA237
SOT23
U301 5185368C66 IC CUSTOM FLIPPER
U302 5187970L15 IC USB TRANS FULL-SPEED
U303 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U304 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U305 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U306 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U308 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U309 5185368C12 IC 1.8V SN LOGIC GATE
U312 5105492X03 IC SNG HI SPD L-MOS NOT
GATE
U401 5185956E51 IC PATRIOT BRAVO 1.0.2
U402 5185956E16 IC FLASH 32MB 1.8V 60NS
U403 5185130C38 IC SRAM 4MG
U404 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U405 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U406 5105492X03 IC SNG HI SPD L-MOS NOT
GATE
U407 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U501 5109879E58 IC, COMP, AUDIO AND
POWER MANAGEMENT
U502 5109731C15 IC OP AMP SNGL OPA237
SOT23
U503 5102463J44 AUDIO AMPLIFIER
TDA8547TS
U505 5185353D13 IC MINI SO-8 HI PRECISION
REG 5V
Ref.
Des.
Motorola Part
Number
Description
U506 5109731C15 IC OP AMP SNGL OPA237
SOT23
U509 5185353D35 IC DUAL EEPOT 256 TAP
U600 5113816A73 IC ADJST 1.7% TOL SHUNT
REG 20MA
U601 5105492X92 IC CMOS BILATERAL SWITCH
U700 5109817F62 IC SPDT SWITCH/
MULTIPLEXER
U701 5109817F62 IC SPDT SWITCH/
MULTIPLEXER
U702 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U703 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U704 5109522E53 IC SNGL BUF NC7S125P5X
SC70
U705 5109522E53 IC SNGL BUF NC7S125P5X
SC70
VR201 4813832C72 TRANS SUP QUAD 12V
VR202 4813830A22 DIODE 9.1V 5% 225MW
MMBZ5239B_
VR204 4813830C26 DIODE 13V ‘H3’
MMSZ5243BT1
VR205 4805656W08 DIODE ZENER QUAD
VR206 4805656W08 DIODE ZENER QUAD
VR207 4805656W08 DIODE ZENER QUAD
VR208 4805656W08 DIODE ZENER QUAD
VR209 4805656W08 DIODE ZENER QUAD
VR220 4805656W03 DIODE DUAL 5.6V ZENER
VR221 4805656W03 DIODE DUAL 5.6V ZENER
Y301 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Ref.
Des.
Motorola Part
Number
Description
