Figure 40 Cascade box
General – Select the cascaded Legacy switch from the Drop-down list.
Input Port No – Select the input port number of the Legacy switch that connects to
the DX Central.
Save changes.
11.4.4 Configuring the server ports
Configure the server ports of cascaded Legacy switches. You must give each server
an identifying name and select the appropriate XRICC type and keyboard mode.
You must also type the appropriate KVM switch access hotkey to the server.
To configure the server ports:
1. In the DX Configuration window, click the desired Legacy switch from the list,
see Figure 41. A figure of the switch ports appears.
Cascaded
input ports
Unconfigured Server
ports
Click the
desired
switch from
the list
Figure 41 Legacy switch configuration
