USER GUIDE
30
Figure 31 Cascade tab
4. General – From the drop-down menu select the lower level DX Central.
5. Input port No: – From the drop-down menu select the lower level User port the
upper level Server port is connected to. For example in Figure 30 Server port 1
is connected to User port 1.
6. Click OK.
Do the above for each cascaded Server port.
After step 1 above, you can achieve the same result by doing the following:
From the toolbar click
. The DX Central Properties box appears. Click the
Cascade Outputs tab. Figure 32 appears.
Figure 32 Cascade Outputs
(Left) Port No: - This is the Server port number.
