DX SYSTEM
21
Figure 19 DX Network Configuration
Here you configure the DX Central’s network settings.
All DX Centrals come with the following predefined settings:
· IP Address: 192.168.0.245
· Subnet Mask: 255.255.255.0
3. If the above predefined settings are not suitable for your network, type suitable
parameters into the DX Network Configuration box.
4. Click . The Define DX status box appears. See Figure 20.
Figure 20 Define DX status box
5. Select Primary unit and click .
6. Click . The Login screen appears.
Before logging in you must configure the slaves.
7. Power on the DX User connected to a slave DX Central. The Configuration
wizard appears as set out above.
8. Check Cascaded DX configuration and click . The DX Network
Configuration box appears. See Figure 19.
