* Rated power consumption. The power supply specifications of the FR series manual controllers and speed controllers are 200VAC 50Hz, 220V/
220VAC 60Hz, and 115VAC 60Hz.
FR Serie
s
M
a
n
u
al
C
o
ntrolle
r/S
p
ee
d
C
o
ntrolle
r
Manual controller FR-AX
For independent operation. With frequency meter, frequency
setting potentiometer and start switch.
Shared among all
models
DC tach. follower FR-AL
For synchronous operation (1.5VA) by external signal (0 to
5V, 0 to 10V DC) *
Three speed selector FR-AT
For three speed switching, among high, middle and low
speed operation (1.5VA) *
Motorized speed setter FR-FK
For remote operation. Allows operation to be controlled from
several places (5VA) *
Ratio setter FR-FH
For ratio operation. Allows ratios to be set to five inverters.
(3VA) *
PG follower FR-FP
For tracking operation by a pilot generator (PG) signal (3VA)
*
Master controller FR-FG
Master controller (5VA) for parallel operation of multiple
(maximum 35) inverters. *
Soft starter FR-FC
For soft start and stop. Enables acceleration/deceleration in
parallel operation (3VA) *
Deviation detector FR-FD
For continuous speed control operation. Used in combination
with a deviation sensor or synchro (5VA) *
Preamplifier FR-FA Used as an A/V converter or arithmetic amplifier (3VA) *
Oth
e
rs
Pilot generator QVAH-10 For tracking operation. 70V/35VAC 500Hz (at 2500r/min)
Deviation sensor YVGC-500W-NS
For continuous speed control operation (mechanical
deviation detection). Output 90VAC/90°
Frequency setting potentiometer WA2W 1k Ω For frequency setting. Wirewound 2W 1k Ω B characteristic
Frequency meter YM206NRI 1mA
Dedicated frequency meter (graduated to 120Hz). Moving-
coil type DC ammeter
Calibration resistor RV24YN 10k Ω
For frequency meter calibration. Carbon film type B
characteristic
Inverter setup software
(FR Configrator)
FR-SW1-SETUP-
WE
Supports an inverter startup to maintenance.
Shared among all
models
Name Type Applications, Specifications, etc.
Applicable
Inverter
