Page 221: Overload curve accuracy -9

GE Multilin
489 Generator Management Relay
7-9
7 TESTING
7.3 ADDITIONAL FUNCTIONAL TESTS
7
7.3ADDITIONAL FUNCTIONAL TESTS
7.3.1 OVERLOAD CURVE ACCURACY
The specification for overload curve timing accuracy is
±100 ms or ±2% of time to trip. Pickup accuracy is as per the current
inputs (
±0.5% of 2 × CT when the injected current is less than 2 × CT and ±1% of 20 × CT when the injected current is equal
to or greater than 2
× CT). Perform the steps below to verify accuracy.
1.
Alter the following setpoints:
S2 SYSTEM SETUP
ÖØ
GEN. PARAMETERS
ÖØ
GENERATOR RATED MVA:
"1.04"
S2 SYSTEM SETUP
ÖØ
GEN. PARAMETERS
ÖØ
GENERATOR VOLTAGE PHASE-PHASE:
"600"
(Note: This is equivalent to setting FLA = 1000 A – For testing purposes ONLY!)
S2 SYSTEM SETUP
Ö
CURRENT SENSING
Ö
PHASE CT PRIMARY:
"1000"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
SELECT CURVE STYLE:
"Standard"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
OVERLOAD PICKUP LEVEL:
"1.10 x FLA"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
UNBALANCE BIAS K FACTOR:
"0"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
HOT/COLD SAFE STALL RATIO:
"1.00"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
ENABLE RTD BIASING:
"No"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
STANDARD OVERLOAD CURVE NUMBER:
"4"
S9 THERMAL MODEL
Ö
MODEL SETUP
ÖØ
ENABLE THERMAL MODEL:
"Yes"
S9 THERMAL MODEL
Ö
THERMAL ELEMENTS
ÖØ
THERMAL MODEL TRIP:
"Latched" or "Unlatched"
2.
Any trip must be reset prior to each test. Short the emergency restart terminals momentarily immediately prior to each
overload curve test to ensure that the thermal capacity used is zero. Failure to do so will result in shorter trip times.
Inject the current of the proper amplitude to obtain the values as shown and verify the trip times. Motor load may be
viewed in:
A2 METERING DATA
Ö
CURRENT METERING
3.
Thermal capacity used and estimated time to trip may be viewed in:
A1 STATUS
ÖØ
GENERATOR STATUS
(EQ 7.4)
AVERAGE PHASE
CURRENT DISPLAYED
PICKUP LEVEL
EXPECTED TIME TO
TRIP
TOLERANCE RANGE
MEASURED TIME TO
TRIP (SEC.)
1050 A
1.05
× FLA
never
n/a
1200 A
1.20
× FLA
795.44 sec.
779.53 to 811.35 sec.
1750 A
1.75
× FLA
169.66 sec.
166.27 to 173.05 sec.
3000 A
3.00
× FLA
43.73 sec.
42.86 to 44.60 sec.
6000 A
6.00
× FLA
9.99 sec.
9.79 to 10.19 sec.
10000 A
10.00
× FLA
5.55 sec.
5.44 to 5.66 sec.
NOTE
FLA
Generator Rated MVA
3 Generator Phase-to-Phase Voltage
Ч
-----------------------------------------------------------------------------------------------------------
=
