489 Generator Management Relay
6-25
6 COMMUNICATIONS
6.3 MODBUS MEMORY MAP
6
POWER ELEMENTS / LOW FORWARD POWER
2280
BLOCK LOW FWD POWER FROM ONLINE
0 to 15000
1
s
F1
0
2281
LOW FORWARD POWER ALARM
0 to 2
1
–
F115
0
2282
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
2283
LOW FWD POWER ALARM LEVEL
2 to 99
1
× Rated MW
F14
5
2285
LOW FWD POWER ALARM DELAY
2 to 1200
1
s
F2
100
2286
LOW FWD POWER ALARM EVENTS
0 to 1
1
–
F105
0
2287
LOW FORWARD POWER TRIP
0 to 2
1
–
F115
0
2288
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
2289
LOW FWD POWER TRIP LEVEL
2 to 99
1
× Rated MW
F14
5
228B
LOW FWD POWER TRIP DELAY
2 to 1200
1
s
F2
200
RTD TEMPERATURE / RTD TYPES
2400
STATOR RTD TYPE
0 to 3
1
–
F120
0
2401
BEARING RTD TYPE
0 to 3
1
–
F120
0
2402
AMBIENT RTD TYPE
0 to 3
1
–
F120
0
2403
OTHER RTD TYPE
0 to 3
1
–
F120
0
RTD TEMPERATURE / RTD #1
2420
RTD #1 APPLICATION
0 to 4
1
–
F121
1
2421
RTD #1 ALARM
0 to 2
1
–
F115
0
2422
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
2423
RTD #1 ALARM TEMPERATURE
1 to 250
1
°C
F1
130
2424
RTD #1 ALARM EVENTS
0 to 1
1
–
F105
0
2425
RTD #1 TRIP
0 to 2
1
–
F115
0
2426
RTD #1 TRIP VOTING
1 to 12
1
–
F122
1
2427
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
2428
RTD #1 TRIP TEMPERATURE
1 to 250
1
°C
F1
155
2429
RTD #1 NAME
0 to 8
1
–
F22
_
RTD TEMPERATURE / RTD #2
2460
RTD #2 APPLICATION
0 to 4
1
–
F121
1
2461
RTD #2 ALARM
0 to 2
1
–
F115
0
2462
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
2463
RTD #2 ALARM TEMPERATURE
1 to 250
1
°C
F1
130
2464
RTD #2 ALARM EVENTS
0 to 1
1
–
F105
0
2465
RTD #2 TRIP
0 to 2
1
–
F115
0
2466
RTD #2 TRIP VOTING
1 to 12
1
–
F122
2
2467
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
2468
RTD #2 TRIP TEMPERATURE
1 to 250
1
°C
F1
155
2469
RTD #2 NAME
0 to 8
1
–
F22
_
RTD TEMPERATURE / RTD #3
24A0
RTD #3 APPLICATION
0 to 4
1
–
F121
1
24A1
RTD #3 ALARM
0 to 2
1
–
F115
0
24A2
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
24A3
RTD #3 ALARM TEMPERATURE
1 to 250
1
°C
F1
130
24A4
RTD #3 ALARM EVENTS
0 to 1
1
–
F105
0
24A5
RTD #3 TRIP
0 to 2
1
–
F115
0
24A6
RTD #3 TRIP VOTING
1 to 12
1
–
F122
3
24A7
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
24A8
RTD #3 TRIP TEMPERATURE
1 to 250
1
°C
F1
155
24A9
RTD #3 NAME
0 to 8
1
–
F22
_
RTD TEMPERATURE / RTD #4
24E0
RTD #4 APPLICATION
0 to 4
1
–
F121
1
24E1
RTD #4 ALARM
0 to 2
1
–
F115
0
24E2
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
24E3
RTD #4 ALARM TEMPERATURE
1 to 250
1
°C
F1
130
24E4
RTD #4 ALARM EVENTS
0 to 1
1
–
F105
0
24E5
RTD #4 TRIP
0 to 2
1
–
F115
0
24E6
RTD #4 TRIP VOTING
1 to 12
1
–
F122
4
24E7
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
24E8
RTD #4 TRIP TEMPERATURE
1 to 250
1
°C
F1
155
24E9
RTD #4 NAME
0 to 8
1
–
F22
_
RTD TEMPERATURE / RTD #5
2520
RTD #5 APPLICATION
0 to 4
1
–
F121
1
2521
RTD #5 ALARM
0 to 2
1
–
F115
0
2522
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
2523
RTD #5 ALARM TEMPERATURE
1 to 250
1
°C
F1
130
2524
RTD #5 ALARM EVENTS
0 to 1
1
–
F105
0
Table 6–1: 489 MEMORY MAP (SHEET 16 OF 24)
ADDR NAME
RANGE
STEP
UNITS
FORMAT
DEFAULT
1, 2, 3
See Table footnotes on page 6–33
