489 Generator Management Relay
6-19
6 COMMUNICATIONS
6.3 MODBUS MEMORY MAP
6
DIGITAL INPUTS / WAVEFORM CAPTURE
13C0
ASSIGN DIGITAL INPUT
0 to 7
1
–
F210
0
DIGITAL INPUTS / GND. SWITCH STATUS
13D0
ASSIGN DIGITAL INPUT
0 to 7
1
–
F210
0
13D1
GROUND SWITCH CONTACT
0 to 1
1
–
F109
0
OUTPUT RELAYS / RELAY RESET MODE
1400
R1 TRIP
0 to 1
1
–
F117
0
1401
R2 AUXILIARY
0 to 1
1
–
F117
0
1402
R3 AUXILIARY
0 to 1
1
–
F117
0
1403
R4 AUXILIARY
0 to 1
1
–
F117
0
1404
R5 ALARM
0 to 1
1
–
F117
0
1405
R6 SERVICE
0 to 1
1
–
F117
0
CURRENT ELEMENTS / OVERCURRENT ALARM
1500
OVERCURRENT ALARM
0 to 2
1
–
F115
0
1501
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
1502
OVERCURRENT ALARM LEVEL
10 to 150
1
× FLA
F3
101
1503
OVERCURRENT ALARM DELAY
1 to 2500
1
s
F2
1
1504
OVERCURRENT ALARM EVENTS
0 to 1
1
–
F105
0
CURRENT ELEMENTS / OFFLINE O/C
1520
OFFLINE OVERCURRENT TRIP
0 to 2
1
–
F115
0
1521
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
1522
OFFLINE OVERCURRENT PICKUP
5 to 100
1
× CT
F3
5
1523
OFFLINE OVERCURRENT TRIP DELAY
3 to 99
1
Cycles
F1
5
CURRENT ELEMENTS / INADVERTENT ENERG.
1540
INADVERTENT ENERGIZE TRIP
0 to 2
1
–
F115
0
1541
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
1542
ARMING SIGNAL
0 to 1
1
–
F202
0
1543
INADVERTENT ENERGIZE O/C PICKUP
5 to 300
1
× CT
F3
5
1544
INADVERTENT ENERGIZE PICKUP
50 to 99
1
× Rated V
F3
50
CURRENT ELEMENTS / PHASE OVERCURRENT
1600
PHASE OVERCURRENT TRIP
0 to 2
1
–
F115
0
1601
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
1602
ENABLE VOLTAGE RESTRAINT
0 to 1
1
–
F103
0
1603
PHASE OVERCURRENT PICKUP
15 to 2000
1
× CT
F3
1000
1604
CURVE SHAPE
0 to 13
1
–
F128
0
1605
FLEXCURVE TRIP TIME AT 1.03
× PU
0 to 65535
1
ms
F1
65535
1606
FLEXCURVE TRIP TIME AT 1.05
× PU
0 to 65535
1
ms
F1
65535
1607
FLEXCURVE TRIP TIME AT 1.10
× PU
0 to 65535
1
ms
F1
65535
1608
FLEXCURVE TRIP TIME AT 1.20
× PU
0 to 65535
1
ms
F1
65535
1609
FLEXCURVE TRIP TIME AT 1.30
× PU
0 to 65535
1
ms
F1
65535
160A
FLEXCURVE TRIP TIME AT 1.40
× PU
0 to 65535
1
ms
F1
65535
160B
FLEXCURVE TRIP TIME AT 1.50
× PU
0 to 65535
1
ms
F1
65535
160C
FLEXCURVE TRIP TIME AT 1.60
× PU
0 to 65535
1
ms
F1
65535
160D
FLEXCURVE TRIP TIME AT 1.70
× PU
0 to 65535
1
ms
F1
65535
160E
FLEXCURVE TRIP TIME AT 1.80
× PU
0 to 65535
1
ms
F1
65535
160F
FLEXCURVE TRIP TIME AT 1.90
× PU
0 to 65535
1
ms
F1
65535
1610
FLEXCURVE TRIP TIME AT 2.00
× PU
0 to 65535
1
ms
F1
65535
1611
FLEXCURVE TRIP TIME AT 2.10
× PU
0 to 65535
1
ms
F1
65535
1612
FLEXCURVE TRIP TIME AT 2.20
× PU
0 to 65535
1
ms
F1
65535
1613
FLEXCURVE TRIP TIME AT 2.30
× PU
0 to 65535
1
ms
F1
65535
1614
FLEXCURVE TRIP TIME AT 2.40
× PU
0 to 65535
1
ms
F1
65535
1615
FLEXCURVE TRIP TIME AT 2.50
× PU
0 to 65535
1
ms
F1
65535
1616
FLEXCURVE TRIP TIME AT 2.60
× PU
0 to 65535
1
ms
F1
65535
1617
FLEXCURVE TRIP TIME AT 2.70
× PU
0 to 65535
1
ms
F1
65535
1618
FLEXCURVE TRIP TIME AT 2.80
× PU
0 to 65535
1
ms
F1
65535
1619
FLEXCURVE TRIP TIME AT 2.90
× PU
0 to 65535
1
ms
F1
65535
161A
FLEXCURVE TRIP TIME AT 3.00
× PU
0 to 65535
1
ms
F1
65535
161B
FLEXCURVE TRIP TIME AT 3.10
× PU
0 to 65535
1
ms
F1
65535
161C
FLEXCURVE TRIP TIME AT 3.20
× PU
0 to 65535
1
ms
F1
65535
161D
FLEXCURVE TRIP TIME AT 3.30
× PU
0 to 65535
1
ms
F1
65535
161E
FLEXCURVE TRIP TIME AT 3.40
× PU
0 to 65535
1
ms
F1
65535
161F
FLEXCURVE TRIP TIME AT 3.50
× PU
0 to 65535
1
ms
F1
65535
1620
FLEXCURVE TRIP TIME AT 3.60
× PU
0 to 65535
1
ms
F1
65535
1621
FLEXCURVE TRIP TIME AT 3.70
× PU
0 to 65535
1
ms
F1
65535
1622
FLEXCURVE TRIP TIME AT 3.80
× PU
0 to 65535
1
ms
F1
65535
1623
FLEXCURVE TRIP TIME AT 3.90
× PU
0 to 65535
1
ms
F1
65535
Table 6–1: 489 MEMORY MAP (SHEET 10 OF 24)
ADDR NAME
RANGE
STEP
UNITS
FORMAT
DEFAULT
