GE Multilin 489 Generator Management Relay 5-23
5 ACTUAL VALUES 5.6 A5 EVENT RECORDER
5
5.6A5 EVENT RECORDER 5.6.1 EVENT RECORDER
PATH: ACTUAL VALUES ÖØ A5 EVENT RECORDER ÖØ [ENTER] EVENT01(40)
„ [ENTER] EVENT01
No Event
TIME OF EVENT01:
00:00:00.0
Range: hour:minutes:seconds
Seen only if there has been an event.
DATE OF EVENT01:
Jan. 01, 1992
Range: month day, year
Seen only if there has been an event.
ACTIVE
GROUP EVENT01: 1
Range: 1, 2
TACHOMETER
EVENT01: 3600 RPM
Range: 0 to 3600 RPM. Seen only if a Digital Input is
programmed as Tachometer
A: 0 B: 0
C: 0 A EVENT01
Range: 0 to 999999 A. Represents current measured
from the output CTs. Seen only if there has been
an event.
a: 0 b: 0
c: 0 A EVENT01
Range: 0 to 999999 A. Represents differential current.
Seen only if the differential element is enabled.
NEG. SEQ. CURRENT
EVENT01: 0% FLA
Range: 0 to 2000% FLA
Seen only if there has been an event.
GROUND CURRENT
EVENT01: 0.00 A
Range: 0.00 to 20000.0 A. Not seen if the GROUND CT
TYPE is programmed as "None".
Vab: 0 Vbc: 0
Vca: 0 V EVENT01
Range: 0 to 50000 V. Not seen if VT CONNECTION is
programmed as "None".
FREQUENCY
EVENT01: 0.00 Hz
Range: 0.00 to 90.00 Hz. Not seen if VT CONNECTION
is programmed as "None".
NEUTRAL VOLT (FUND)
EVENT01: 0.0 V
Range: 0.0 to 25000.0 V. Seen only if there is a neutral
voltage transformer.
NEUTRAL VOLT (3rd)
EVENT01: 0.0 V
Range: 0.0 to 25000.0 V. Seen only if there is a neutral
voltage transformer.
Vab/Iab EVENT01:
0.0
Ωsec.
0°
Range: 0.0 to 6553.5 Ωsec., 0 to 359°. Seen only if the
Loss of Excitation element is Enabled.
REAL POWER (MW)
EVENT01: 0.000
Range: 0.000 to ±2000.000 MW. Not seen if VT
CONNECTION is programmed as "None"
REACTIVE POWER Mvar
EVENT01: 0.000
Range: 0.000 to ±2000.000 Mvar. Not seen if VT
CONNECTION is programmed as "None"
APPARENT POWER MVA
EVENT01: 0.000
Range:0.000 to 2000.000 MVA. Not seen if VT
CONNECTION is programmed as "None"
HOTTEST STATOR
RTD#1: 0°C EVENT01
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Stator.
HOTTEST BEARING
RTD#7: 0°C EVENT01
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Bearing.
HOTTEST OTHER
RTD#11: 0°C EVENT01
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Other.
AMBIENT
RTD#12 0°C EVENT01
Range: –50 to +250°C. Seen only if 1 or more RTDs are
programmed as Ambient.
ANALOG INPUT 1
EVENT01: 0.0 Units
Range: –50000 to 50000
Seen only if the Analog Input is in use.
