GE 489 User Manual
Page 184
6-22
489 Generator Management Relay
GE Multilin
6.3 MODBUS MEMORY MAP
6 COMMUNICATIONS
6
1761
FLEXCURVE TRIP TIME AT 8.50
× PU
0 to 65535
1
ms
F1
65535
1762
FLEXCURVE TRIP TIME AT 9.00
× PU
0 to 65535
1
ms
F1
65535
1763
FLEXCURVE TRIP TIME AT 9.50
× PU
0 to 65535
1
ms
F1
65535
1764
FLEXCURVE TRIP TIME AT 10.0
× PU
0 to 65535
1
ms
F1
65535
1765
FLEXCURVE TRIP TIME AT 10.5
× PU
0 to 65535
1
ms
F1
65535
1766
FLEXCURVE TRIP TIME AT 11.0
× PU
0 to 65535
1
ms
F1
65535
1767
FLEXCURVE TRIP TIME AT 11.5
× PU
0 to 65535
1
ms
F1
65535
1768
FLEXCURVE TRIP TIME AT 12.0
× PU
0 to 65535
1
ms
F1
65535
1769
FLEXCURVE TRIP TIME AT 12.5
× PU
0 to 65535
1
ms
F1
65535
176A
FLEXCURVE TRIP TIME AT 13.0
× PU
0 to 65535
1
ms
F1
65535
176B
FLEXCURVE TRIP TIME AT 13.5
× PU
0 to 65535
1
ms
F1
65535
176C
FLEXCURVE TRIP TIME AT 14.0
× PU
0 to 65535
1
ms
F1
65535
176D
FLEXCURVE TRIP TIME AT 14.5
× PU
0 to 65535
1
ms
F1
65535
176E
FLEXCURVE TRIP TIME AT 15.0
× PU
0 to 65535
1
ms
F1
65535
176F
FLEXCURVE TRIP TIME AT 15.5
× PU
0 to 65535
1
ms
F1
65535
1770
FLEXCURVE TRIP TIME AT 16.0
× PU
0 to 65535
1
ms
F1
65535
1771
FLEXCURVE TRIP TIME AT 16.5
× PU
0 to 65535
1
ms
F1
65535
1772
FLEXCURVE TRIP TIME AT 17.0
× PU
0 to 65535
1
ms
F1
65535
1773
FLEXCURVE TRIP TIME AT 17.5
× PU
0 to 65535
1
ms
F1
65535
1774
FLEXCURVE TRIP TIME AT 18.0
× PU
0 to 65535
1
ms
F1
65535
1775
FLEXCURVE TRIP TIME AT 18.5
× PU
0 to 65535
1
ms
F1
65535
1776
FLEXCURVE TRIP TIME AT 19.0
× PU
0 to 65535
1
ms
F1
65535
1777
FLEXCURVE TRIP TIME AT 19.5
× PU
0 to 65535
1
ms
F1
65535
1778
FLEXCURVE TRIP TIME AT 20.0
× PU
0 to 65535
1
ms
F1
65535
1779
OVERCURRENT CURVE MULTIPLIER
0 to 100000
1
–
F14
100
177B
OVERCURRENT CURVE RESET
0 to 1
1
–
F201
0
CURRENT ELEMENTS / PHASE DIFFERENTIAL
17E0
PHASE DIFFERENTIAL TRIP
0 to 2
1
–
F115
0
17E1
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
17E2
DIFFERENTIAL TRIP MIN. PICKUP
5 to 100
1
× CT
F3
10
17E3
DIFFERENTIAL TRIP SLOPE 1
1 to 100
1
%
F1
10
17E4
DIFFERENTIAL TRIP SLOPE 2
1 to 100
1
%
F1
20
17E5
DIFFERENTIAL TRIP DELAY
0 to 100
1
cycles
F1
0
CURRENT ELEMENTS / GROUND DIRECTIONAL
1800
SUPERVISE WITH DIGITAL INPUT
0 to 1
1
–
F103
1
1801
GROUND DIRECTIONAL MTA
0 to 3
1
–
F217
0
1802
GROUND DIRECTIONAL ALARM
0 to 2
1
–
F115
0
1803
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
1804
GROUND DIR. ALARM PICKUP
5 to 2000
1
× CT
F3
5
1805
GROUND DIR. ALARM DELAY
1 to 1200
1
s
F2
30
1806
GROUND DIR. ALARM EVENTS
0 to 1
1
–
F105
0
1807
GROUND DIRECTIONAL TRIP
0 to 2
1
–
F115
0
1808
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
1809
GROUND DIR. TRIP PICKUP
5 to 2000
1
× CT
F3
5
180A
GROUND DIR. TRIP DELAY
1 to 1200
1
s
F2
30
CURRENT ELEMENTS / HIGH-SET PHASE O/C
1830
HIGH-SET PHASE O/C TRIP
0 to 2
1
–
F115
0
1831
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
1832
HIGH-SET PHASE O/C PICKUP
15 to 2000
1
× CT
F3
500
1833
HIGH-SET PHASE O/C DELAY
0 to 10000
1
s
F3
100
VOLTAGE ELEMENTS / UNDERVOLTAGE
2000
UNDERVOLTAGE ALARM
0 to 2
1
–
F115
0
2001
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
2002
UNDERVOLTAGE ALARM PICKUP
50 to 99
1
× Rated
F3
85
2003
UNDERVOLTAGE ALARM DELAY
2 to 1200
1
s
F2
30
2004
UNDERVOLTAGE ALARM EVENTS
0 to 1
1
–
F105
0
2005
UNDERVOLTAGE TRIP
0 to 2
1
–
F115
0
2006
ASSIGN TRIP RELAYS (1-4)
0 to 3
1
–
F50
1
2007
UNDERVOLTAGE TRIP PICKUP
50 to 99
1
× Rated
F3
80
2008
UNDERVOLTAGE TRIP DELAY
2 to 100
1
s
F2
10
2009
UNDERVOLTAGE CURVE RESET RATE
0 to 9999
1
s
F2
14
200A
UNDERVOLTAGE CURVE ELEMENT
0 to 1
1
–
F208
0
VOLTAGE ELEMENTS / OVERVOLTAGE
2020
OVERVOLTAGE ALARM
0 to 2
1
–
F115
0
2021
ASSIGN ALARM RELAYS (2-5)
1 to 4
1
–
F50
16
2022
OVERVOLTAGE ALARM PICKUP
101 to 150
1
× Rated
F3
115
Table 6–1: 489 MEMORY MAP (SHEET 13 OF 24)
ADDR NAME
RANGE
STEP
UNITS
FORMAT
DEFAULT
1, 2, 3
See Table footnotes on page 6–33
