GE 489 User Manual
Page 206
6-44
489 Generator Management Relay
GE Multilin
6.5 DNP POINT LISTS
6 COMMUNICATIONS
6
Any detected change in the state of any point assigned to Class 1 will cause the generation of an event object.
85
Loss of Excitation Circle 2 Trip Active
or Latched
Class 1
86
Ground Directional Trip Active or
Latched
Class 1
87
High Set Phase O/C Trip Active or
Latched
Class 1
88
Distance Zone 1 Trip Active or Latched
Class 1
89
Distance Zone 2 Trip Active or Latched
Class 1
90
… Reserved …
↓
↓
↓
99
… Reserved …
100
Assignable In 1 Alarm Active / Latched
Class 1
101
Assignable In 2 Alarm Active or
Latched
Class 1
102
Assignable In 3 Alarm Active or
Latched
Class 1
103
Assignable In 4 Alarm Active or
Latched
Class 1
104
Assignable In 5 Alarm Active or
Latched
Class 1
105
Assignable In 6 Alarm Active or
Latched
Class 1
106
Assignable In 7 Alarm Active / Latched
Class 1
107
Tachometer Alarm Active or Latched
Class 1
108
Overcurrent Alarm Active or Latched
Class 1
109
Neg Seq Alarm Active or Latched
Class 1
110
Ground O/C Alarm Active or Latched
Class 1
111
Undervoltage Alarm Active or Latched
Class 1
112
Overvoltage Alarm Active or Latched
Class 1
113
Volts/Hertz Alarm Active or Latched
Class 1
114
Underfreq Alarm Active or Latched
Class 1
115
Overfrequency Alarm Active or
Latched
Class 1
116
Neutral O/V (fundamental) Alarm
Active or Latched
Class 1
117
Neutral U/V (3
rd
harm) Alarm Active or
Latched
Class 1
118
Reactive Power Alarm Active or
Latched
Class 1
119
Reverse Power Alarm Active or
Latched
Class 1
120
Low Fwd Power Alarm Active /
Latched
Class 1
121
RTD #1 Alarm Active or Latched
Class 1
122
RTD #2 Alarm Active or Latched
Class 1
123
RTD #3 Alarm Active or Latched
Class 1
124
RTD #4 Alarm Active or Latched
Class 1
125
RTD #5 Alarm Active or Latched
Class 1
Table 6–5: BINARY INPUT POINTS (SHEET 3 OF 4)
INDEX DESCRIPTION
EVENT
CLASS
126
RTD #6 Alarm Active or Latched
Class 1
127
RTD #7 Alarm Active or Latched
Class 1
128
RTD #8 Alarm Active or Latched
Class 1
129
RTD #9 Alarm Active or Latched
Class 1
130
RTD #10 Alarm Active or Latched
Class 1
131
RTD #11 Alarm Active or Latched
Class 1
132
RTD #12 Alarm Active or Latched
Class 1
133
Open Sensor Alarm Active or Latched
Class 1
134
Short/Low Temp Alarm Active /
Latched
Class 1
135
Thermal Model Alarm Active or
Latched
Class 1
136
Trip Counter Alarm Active or Latched
Class 1
137
Breaker Failure Alarm Active or
Latched
Class 1
138
Trip Coil Monitor Alarm Active /
Latched
Class 1
139
VTFF Alarm Active or Latched
Class 1
140
Current Dmd Alarm Active or Latched
Class 1
141
MW Demand Alarm Active or Latched
Class 1
142
Mar Demand Alarm Active or Latched
Class 1
143
MVA Alarm Active or Latched
Class 1
144
Analog Input 1 Alarm Active or
Latched
Class 1
145
Analog Input 2 Alarm Active or
Latched
Class 1
146
Analog Input 3 Alarm Active or
Latched
Class 1
147
Analog Input 4 Alarm Active or
Latched
Class 1
148
Not Programmed Alarm Active /
Latched
Class 1
149
Simulation Mode Alarm Active or
Latched
Class 1
150
Output Relays Forced Alarm Active or
Latched
Class 1
151
Analog Output Forced Alarm Active or
Latched
Class 1
152
Test Switch Shorted Alarm Active or
Latched
Class 1
153
Gnd Directional Alarm Active or
Latched
Class 1
154
IRIG-B Failure Alarm Active or Latched
Class 1
155
Generator Running Hour Alarm Active
or Latched
Class 1
Table 6–5: BINARY INPUT POINTS (SHEET 4 OF 4)
INDEX DESCRIPTION
EVENT
CLASS
NOTE
