5-2 489 Generator Management Relay GE Multilin
5.1 OVERVIEW 5 ACTUAL VALUES
5
In addition to the actual value messages, there are also diagnostic and flash messages that appear only when certain con-
ditions occur. They are described later in this chapter.
„„ A3 ACTUAL VALUES
„„ LEARNED DATA „ PARAMETER AVERAGES
„ [ENTER] for more
See page 5–18.
„ RTD MAXIMUMS
„ [ENTER] for more
See page 5–18.
„ ANALOG IN MIN/MAX
„ [ENTER] for more
See page 5–19.
„„ A4 ACTUAL VALUES
„„ MAINTENANCE „ TRIP COUNTERS
„ [ENTER] for more
See page 5–20.
„ GENERAL COUNTERS
„ [ENTER] for more
See page 5–22.
„ TIMERS
„ [ENTER] for more
See page 5–22.
„„ A5 ACTUAL VALUES
„„ EVENT RECORD „ [ENTER] EVENT 01
„ [ENTER] for more
See page 5–23.
„ [ENTER] EVENT 02
„ [ENTER] for more
↓
„ [ENTER] EVENT 40
„ [ENTER] for more
„„ A6 ACTUAL VALUES
„„ PRODUCT INFO. „ 489 MODEL INFO.
„ [ENTER] for more
See page 5–25.
„ CALIBRATION INFO.
„ [ENTER] for more
See page 5–25.
