5.3 A2 METERING DATA 5 ACTUAL VALUES
5
5.3.4 TEMPERATURE
PATH: ACTUAL VALUES ÖØ A2 METERING DATA ÖØ TEMPERATURE
The current level of the 12 RTDs will be displayed here. If the RTD is not connected, the value will be "No RTD". If no RTDs
are programmed in the
S7 RTD TEMPERATURE setpoints menu, the THIS FEATURE NOT PROGRAMMED flash message will
appear when an attempt is made to enter this group of messages.
„ TEMPERATURE
„ [ENTER] for more
HOTTEST STATOR RTD
RTD#1: 40°C
Range: –50 to 250°C, No RTD
Seen only if at least 1 RTD programmed as
Stator
RTD #1
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD. Not seen if RTD
programmed as None. Value reflects the RTD
Name as programmed
RTD #2
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #3
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #4
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #5
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #6
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #7
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #8
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #9
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #10
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #11
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
RTD #12
TEMPERATURE: 40°C
Range: see RTD #1 TEMPERATURE above
