Gateway 9315 User Manual
Page 67
62
www.gateway.com
9
Press and hold the C
TRL
key, then press the E key. The RAID BIOS console will open.
10
Configure the RAID options, then exit the RAID BIOS console.
11
Reboot the server.
To configure the SATA RAID solution:
1
Open the BIOS Setup utility as described in the previous procedure.
2
Select
Configure
from the
Management
menu, then select
Easy Configuration
.
3
Press the S
PACEBAR
to associate the selected physical drives with the current array. The
indicator changes from READY to ONLINE.
4
Press
Enter
when you finish creating the current array, then press F10 to select
configurable arrays.
Important
When you press
C
TRL
+ E
to configure the SATA RAID, you will see
the following error message:
Error (0146): Insufficient Memory
to Shadow PCI ROM. This error message can be ignored.
