Gateway 9315 User Manual
Page 62
57
www.gateway.com
12
Connect the SATA power cable adapter end(s) to the rear of the SATA drive.
13
Reinstall the bezel, if required, by snapping it into place on the front of the chassis.
14
Follow the instructions in
“Closing the server case” on page 39
.
15
Reconnect all power cords and peripheral device cables, then turn on the server.
Important
Power cables for drives installed to the right side of the air baffle must
be routed beneath the front cutout in the underside of the air baffle.
The power cable for a drive installed to the left of the air baffle does
not need to be routed under the air baffle. You may need to remove
the air baffle to route cables underneath it.
Air baffle cutout
Air baffle
