Page 44
39
www.gateway.com
6
Press and hold the panel release button, then slide the top panel toward the back of
the server about 1/2 inch.
7
Lift the top panel away from the server.
Closing the server case
To close the server case:
1
Make sure that all of the internal cables are arranged inside the case so they will not
be pinched when you close the case.
2
Slide the top panel’s edges into the server.
Caution
Whenever you add or remove components from your server, make
sure that the various cables, both data and power, are routed correctly
before reinstalling the top panel. Incorrectly routed cables could result
in cable damage, fan blockage, misalignment of baffles and ducts,
and incorrect airflow within the server.
Panel release
button
