Connectors - left side

PCI riser card (low-profile)

PCI riser card (full-height)

DIMM slots

Battery

Mouse (top)

and

Keyboard

Serial port A header

Chassis intrusion header

BIOS select jumper

ID LED

Diagnostic LEDs (4)

USB 2

USB 1

Video

LAN 2

LAN 1

Serial port B (RJ-45)
