System board
Connectors - right side
CPU 1
socket
IDE power
connector
CPU 1 fan header
CPU 2
socket
+12V CPU power connector
Fan board connector
Diskette connector
PCI fan connectors
IDE connector
100-pin floppy/front
panel/ATA connector
50-pin front panel connector
Main power connector
Front panel USB header
Configuration jumpers
SATA 1 connector
OEM RMC connector
CPU 2 fan header
34-pin front panel connector
SATA 0 connector Power supply connector
