98 Appendix A
pnic loadrules
Upload to the FPGA the dynamic rules for both channels encoded in the files /usr/local/pnic/
0/pnic_{0|1}.bin.
Syntax
pnic loadrules [channel]
Parameters
Command
History
Example Figure 61
root@# pnic loadrules 0
dynamic rules loaded
pnic loadrules Command Example
Usage
Information
Capture/block policies previously stored are temporarily disabled during this operation and
traffic is forwarded. The new rules take effect when the loading process is complete.
Address 24
(PCI-X FPGA) This address is mapped to the parameter Burst size (measured in 32-bit
words). This parameter sets the number of 32-bit words to transfer in one
PCI-X master cycle. Larger bursts achieve higher throughput but may
increase buffering latency and contention with other devices sharing the
same bus. The default value is 1024.
Address 36
(PCI-X FPGA)
This address specifies the count in PCI-X clocks before the DMA buffer is
transferred to the host if the buffer contains less than the programmed
burst size.
Table 27 Loadparams Address Mapping
Address Corresponding Parameter
channel
Enter the channel number
Range: 0-1
Default: 0
Version 2.0.0.1 Introduced
