32 Graphical User Interface
The remaining lines report the cumulative number of events and the rate of those events. A description of
each line is given in
Table 6 .
Figure 19
CPU(s): 0.0% user, 0.0% system, 0.0% nice, 100.0% idle
Dev: 8002 - Type: PNIC-0 - FirmwareID: 64 - Ver:2.6 - DefaultDrop: disabled
pnic0 UP Capture=on FlowTimeout=16 Packets/flow=0 Truncation=0 Irq period=1ms
HW Interfaces CH0 Top Rate/s CH1 Top Rate/s
Total Packets 0 0 0 0
TCP Packets 0 0 0 0
UDP Packets 0 0 0 0
ICMP Packets 0 0 0 0
Other Packets 0 0 0 0
Capture Packets 0 0 0 0
Total Flows 0 0 0 0
Delayed Pkts 0 0 0 0
Stateful Pkts 0 0 0 0
Blocked Packets 0 0 0 0
OS Interface pnic0:0 Rate/s pnic0:1 Rate/s
Rx (Packets) 2838226 0 2838042 0
Rx (Bytes) 1408250941 0 1407263719 0
Rx (Bits) 2676072936 0 2668175160 0
Errors 0 0 0 0
Truncated (Pkts) 0 0 0 0
h=help z=stop m=manage_rules c=truncation t=timeout f=packets/flow x=DMA
Runtime Statistics for Channel 0 and 1—FPGA Loaded
Figure 20
CPU(s): 0.0% user, 0.0% system, 0.0% nice, 100.0% idle
Dev: 8002 - Type: PNIC-0 - FirmwareID: 64 - Ver:2.6 - DefaultDrop: disabled
pnic0 UP Capture=on FlowTimeout=16 Packets/flow=0 Truncation=0 Irq period=1ms
HW Interfaces CH0 Top Rate/s CH1 Top Rate/s
Total Packets 0 0 0 0
TCP Packets 0 0 0 0
UDP Packets 0 0 0 0
ICMP Packets 0 0 0 0
Other Packets 0 0 0 0
Capture Packets 0 0 0 0
Total Flows 0 0 0 0
Delayed Pkts 0 0 0 0
Stateful Pkts 0 0 0 0
Blocked Packets 0 0 0 0
OS Interface pnic0 Rate/s
Rx (Packets) 5676268 0
Rx (Bytes) 2815514660 0
Rx (Bits) 1049280800 0
Errors 0 0
Truncated (Packets) 0 0
h=help z=stop m=manage_rules c=truncation t=timeout f=packets/flow x=DMA
Cumulative Runtime Statistics for Channels 0 and 1—FPGA Loaded
