P-Series Installation and Operation Guide, version 2.3.1.2
13
Warning: Stop all traffic from flowing through the appliance, and disconnect all cables from the XFPs
before proceeding.
Step
Task
Command
1
Save earlier configuration files and firmware by
copying the directory /usr/local/pnic to the home
directory.
cp -Rf /usr/local/pnic/ /home
2
Create a new sub-directory in the home directory for
the upgrade package.
mkdir ~/upgrade_directory
3
From the root directory, secure copy the file filename
from a server to the upgrade directory you created.
Note: In Unix, the tilde symbolizes the home directory,
and can be used in place of the absolute path to the
home directory. The upgrade file is a Unix tarball, the
file extension of which is .tar.gz.
scp username@server:absolute_path/
filename ~/upgrade_directory
4
Change directory to upgrade directory you created.
cd upgrade_directory
5
Untar the file PTPS-P_MAIN.
tar xvzf PTPS-P_MAIN
6
Change directory to SW.
cd SW
7
Enter the command
gmake erase followed by
gmake.
gmake erase
gmake
8
Enter the command
gmake install.
gmake install
9
Verify that the new software version is installed.
pnic cardstatus
Warning: The remainder of this procedure is for upgrading the boot firmware. The boot firmware
upgrade process takes up to 30 minutes and must not be interrupted. If the process is interrupted, the
boot firmware must be reloaded via JTAG, which requires an RMA.
10
Enter the command
pnic loadeproms to upgrade the
boot firmware. Answer “yes” to the confirmation
question.
Note: This process takes up to 30 minutes.
pnic loadeproms
11
Reboot the appliance.
Note: Reboot the appliance only after
pnic
loadeproms has successfully finished.
shutdown -r now
12
Log into the appliance and enter the command
pnic
cardstatus. Verify that there is an output for this
command. This indicates that the upgrade process has
been completed successfully.
Note: See
for an example
output for this command.
pnic cardstatus
